Tehničke specifikacije
Printing Technology LPD (Layer Plastic Deposition) / FFF
Layer resolution 90-390 microns
Minimal wall thickness 400 microns
Platform levelling Automatic platform points height measurement
Build volume 200 x 200 x 180mm
Material container Spool
Material diameter 1.75 mm
Nozzle diameter 0.4 mm
Support Mechanically removed – printed from the same material as the model
Extruder Single (upgraded for experimental materials)
Connectivity USB, RJ45, WiFi
New cooling system Double fan and extruder cooling
Hotend V3 and nozzle with new geometry
Material runout Mechanical endstop
Build plate Perforated plate with pegopins instead of small connector
Materials M Series dedicated materials (recommended)
External materials Applicable
Platform leveling Auto
Touchscreen 4″ IPS 800 x 480
Dimensional accuracy +/- 0,2%*
Angle accuracy +/- 0,2%**
Maximum printing temperature (extruder) 290° C
Build platform Heated
Processor Quad Core
Operation system Andrioid
Maximum platform temperature 105° C
Ambient operation temperature 20° – 30° C
Storage temperature 0° – 35° C
Electrical 240 V ~ 1.7 A 50/60 Hz
Maximum power consumption 320 W
Software bundle Z-SUITE 2.0
Supported file types .stl, .obj, .dxf, .3mf
Supported operating systems Mac OS X / Windows 7 and newer versions
