The printer now automatically opens the vent for low-temperature materials (PLA, PETG) and closes it for high-temp materials in a true set-and-forget fashion.
A redesigned filament insertion point makes feeding flexible filaments like TPU quick and simple. No more fighting with soft materials at the entry point.
Accommodates various spool sizes and is ready for a direct-feed drybox setup. Swap spools faster, use any brand without adapters.
Every software improvement developed throughout the CORE One lifespan is included – better print profiles, smoother motion, improved sensors. Most refined version from day one.
Build Volume – 250 × 220 × 270 mm | 9.8 × 8.6 × 10.6 in
Filament diameter – 1.75 mm
Layer height – 0.05-0.30 mm
Printer dimensions – 22.5 kg, 415 × 444 × 555 mm; 16.3 × 17.5 × 21.8 in (X×Y×Z)
Mainboard – Custom 32-bit xBuddy electronics with STM32
Stepper Drivers – Trinamic 2130
Stepper motors – Precise 0.9° X,Y stepper motors (prevents VFA)
Extruder – Nextruder, Direct Drive, E3D V6 compatible (with adapter)
Extruder electronics – Custom breakout board for connecting fans, thermistors and other parts
Filament path – Aluminum heatsink, all-metal hotend
Drive system – Nextruder Planetary Gear System, 10:1 gearbox ratio
Cooling fan – High-performance turbine, 360° cooling system
Nozzle – High-flow Prusa Nozzle brass CHT – 0.4 mm
Max nozzle temperature – 290 °C / 554 °F
Max heatbed temperature – 120 °C / 248 °F
Max chamber temperature – 55 °C / 131 °F
LCD screen – 3.5″ graphic 65k color screen
Touch control – Yes
Firmware update interface – USB drive, Prusa Connect, Prusa Mobile App
Prusa Connect support – Yes
Quick-Swap nozzle system – Yes
Internal camera – Optional, in-chamber solution
Multi-Material Support – Yes, MMU3 (5 filaments) and INDX (up to 8 filaments)
HEPA filtration – Optional addon
Connectivity – Ethernet, Wi-Fi (NFC receiver, optional Wi-Fi module)
Filament Sensor – Yes (2 sensors)
Loadcell sensor – Yes
Print surface – Magnetic heatbed with removable PEI spring steel sheets
First layer calibration – Fully automatic (Load Cell sensor)
Input shaper – Yes
Supported materials – PLA, PETG, Flex, PVA, PC, PP, CPE, PVB (Advanced: ABS, ASA, HIPS, PA)
PSU – 240W with Power Panic HW
Power consumption – PLA: 90W / ABS: 110W
